Instrument Classification Type: | Class II | Certificates: | ISO13485/ FDA |
---|---|---|---|
Length: | 30 Cm | Logo Printing: | Customized |
Material: | Polyurethane Sleeve | Quality Guarantee Period: | Five Years |
Sterility: | Sterile | Type Of Sterilization: | Ethylene Oxide Sterilization |
Usage: | Single Use | Size: | 10Fr,12 Fr,14Fr,16Fr |
L-Piece Soft Blue Suction Tip Design Closed Suction Catheter/System 24H For Patient Comfort
- It is designed with a protective sleeve to isolate the germs inside and help caregivers avoid cross-infection.
-Simultaneous ventilation design will allow the patients' comfort of suctioning without stopping the air ventilation.
-Automatic Flushing Closed Suction System is the only catheter that retracts within a unique and isolated turbulent cleaning chamber. The turbulent cleansing action results in an 89% cleaner catheter tip compared to a standard closed suction system. This reduced colonization may help reduce the risk of VAE and VAP in your ventilated patients.
-A turbulent cleaning chamber creates cleansing action, resulting in a cleaner catheter.
-Hinged valve isolates catheter tip and helps prevent inadvertent lavage.
-Integrated MDI port
Feature
- Continuous Breathing
Simultaneous ventilation
- Soft Blue Suction Tip
This design reduces damage to the patient while suctioning.
After returning the catheter, the tip of the tube is easier for irrigational cleaning.
- Disconnecting Wedge
Designed to equip the wedge with both disconnecting and clipping functions
- For Endotracheal Tube and Tracheostomy Tube
Designed for endotracheal and tracheostomy tube using
Tube with different lengths are available
- Prevent Cross Infection
Designed with a protective sleeve to isolate the bacteria inside and help caregivers avoid cross-inflection.
Product Data Sheet
Product Code | Size | Colour Code | Tube OD (mm) | Length of Tube (mm) |
MC-02400 | Neonatal/24H/Tracheostomy | Grey | 5Fr(1.7mm) | 300mm |
MC-02401 | Neonatal//24H/Tracheostomy | Light Green | 6Fr(1.95mm) | 300mm |
MC-02402 | Pediatric/24H/Tracheostomy | Lvory | 7Fr(2.3mm) | 300mm |
MC-02403 | Pediatric//24H/Tracheostomy | Light Blue | 8Fr(2.7mm) | 300mm |
MC-02404 | Adult/24H/Tracheostomy | Black | 10Fr(3.35mm) | 300mm |
MC-02405 | Adult/24H/Tracheostomy | White | 12Fr(4.05mm) | 300mm |
MC-02406 | Adult/24H/Tracheostomy | Green | 14Fr(4.75mm) | 300mm |
MC-02407 | Adult/24H/Tracheostomy | Orange | 16Fr(5.45mm) | 300mm |
Product Code | Size | Colour Code | Tube OD (mm) | Length of Tube (mm) |
MC-02410 | Neonatal/24H/Endotracheal | Grey | 5Fr(1.7mm) | 300mm |
MC-02411 | Neonatal//24H/Endotracheal | Light Green | 6Fr(1.95mm) | 300mm |
MC-02412 | Pediatric/24H/Endotracheal | Lvory | 7Fr(2.3mm) | 300mm |
MC-02413 | Pediatric//24H/Endotracheal | Light Blue | 8Fr(2.7mm) | 300mm |
MC-02414 | Adult/24H/Endotracheal | Black | 10Fr(3.35mm) | 600mm |
MC-02415 | Adult/24H/Endotracheal | White | 12Fr(4.05mm) | 600mm |
MC-02416 | Adult/24H/Endotracheal | Green | 14Fr(4.75mm) | 600mm |
MC-02417 | Adult/24H/Endotracheal | Orange | 16Fr(5.45mm) | 600mm |
