| Brand Name: | MCR / OEM |
| Model Number: | MC-22400 |
| MOQ: | 1 Pieces |
| Price: | 2.2-4.5usd/pc |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 50,000-100,000PCS/Month |
Disposable Double Swivel Elbow Closed Suction Catheter 24H Y-Piece
Data Sheet
| Closed Suction Catheter Y-Piece 24H | ||||
| REF(Product ID Number) | Size(product variable) | Color Code | Tube OD (mm) | Length Of Tube(mm) |
| MC-22400 | Neonatal/24H/Tracheostomy | Grey | 5FR(1.7mm) | 300mm |
| MC-22401 | Neonatal/24H/Tracheostomy | Light Green | 6FR(1.95mm) | 300mm |
| MC-22402 | Pediatric/24H/Tracheostomy | Ivory | 7FR(2.3mm) | 300mm |
| MC-22403 | Pediatric/24H/Tracheostomy | Light Blue | 8FR(2.7mm) | 300mm |
| MC-22404 | Adult/24H/Tracheostomy | Black | 10FR(3.35mm) | 300mm |
| MC-22405 | Adult/24H/Tracheostomy | White | 12FR(4.05mm) | 300mm |
| MC-22406 | Adult/24H/Tracheostomy | Green | 14FR(4.75mm) | 300mm |
| MC-22407 | Adult/24H/Tracheostomy | Orange | 16FR(5.45mm) | 300mm |
| MC-22410 | Neonatal/24H/Endotracheal | Grey | 5FR(1.7mm) | 300mm |
| MC-22411 | Neonatal/24H/Endotracheal | Light Green | 6FR(1.95mm) | 300mm |
| MC-22412 | Pediatric/24H/Endotracheal | Ivory | 7FR(2.3mm) | 300mm |
| MC-22413 | Pediatric/24H/Endotracheal | Light Blue | 8FR(2.7mm) | 300mm |
| MC-22414 | Adult/24H/Endotracheal | Black | 10FR(3.35mm) | 600mm |
| MC-22415 | Adult/24H/Endotracheal | White | 12FR(4.05mm) | 600mm |
| MC-22416 | Adult/24H/Endotracheal | Green | 14FR(4.75mm) | 600mm |
| MC-22417 | Adult/24H/Endotracheal | Orange | 16FR(5.45mm) | 600mm |
Feature:
Allows continuous ventilation during suctioning procedure, preventing oxygen desaturation and loss of lung volume
Closed circuit preventing cross contamination and infection
Double swivel elbow connector
MDI port for quick and effective drug delivery
One way valve for flushing catheter
Catheter with clearly visible graduation and rounded tip to minimize the risk of trachea mucosa damaging
Double black markings of catheter withdrawal
Colour coded sizes of suction catheter
Suction control button with built-in locking system to prevent accidental pressing
